Picture/Display
- Panel Size: 34 inch / 86.36 cm
- Aspect Ratio: 21:9
- LCD Panel Type: VA LCD
- Backlight Type: W-LED system
- Pixel Pitch: 0.23175 x 0.23175 mm
- Brightness: 300 cd/m²
- Display Colors: 1.07B (10 bits)
- Color Gamut (typical): NTSC area: 111.87%, sRGB area: 120.46%
- Contrast Ratio (typical): 3500:1
- SmartContrast: 50,000,000:1
- Response Time (typical): 4 ms (Gray to Gray)
- Viewing Angle: 178º (H) / 178º (V) @ C/R > 10
- Maximum Resolution: 3440x1440 @ 100Hz (HDMI), 3440x1440 @ 120Hz (DP/USBC)
- Effective Viewing Area: 797.22 (H) x 333.72 (V) - at a 1500R curvature
- Scanning Frequency: HDMI: 30K-160KHz (H) / 48 - 100 Hz (V), DP/USB-C : 30-190KHz (H) / 48 - 120 Hz (V)
- Pixel Density: 110 PPI
- Display Screen Coating: Anti-Glare, 3H, Haze 25%
- Picture Enhancement: SmartImage
- Features: sRGB, SoftBlue, Flicker-free, EasyRead, Adaptive sync (VRR), EyeSafe
Connectivity & USB Hub
- Signal Input: HDMI 2.0 x 1, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, data, PD)
- USB Hub: USB 3.2, Gen1, 5Gbps
- USB Upstream: USB-C1(Full) / USB-B
- USB Downstream: USB-A x 4 (with x1 fast charge B.C 1.2)
- Audio (In/Out): Audio out x 1
- RJ45: Ethernet LAN (USB 2.0: 10M/100M; USB 3.0: 1000M), PXE/MAPT/WOL
- HDCP: HDCP 1.4 (HDMI / DP / USB-C); HDCP 2.2 (HDMI / DP / USB-C)
- Sync Input: Separate Sync
Power Delivery (USB-C)
- Version: USB PD version 3.0
- Max Power Delivery: Up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A)
Convenience & Audio
- Built-in Speakers: 5 W x 2
- MultiView: 2x devices (PIP/PBP mode)
- SmartKVM: Yes (USB-C/USB-B)
- Other Convenience: Kensington lock, Earphone hook, VESA mount (100x100mm)
Stand Adjustments
- Height Adjustment: 180 mm
- Swivel: -/+ 180 degree
- Tilt: -5 / 30 degree
Power Consumption
- Power Supply: Built-in 100-240VAC, 50-60Hz
- ECO Mode: 20.2 W (typ.)
- On Mode: 28.19 W (typ.) (EnergyStar test method)
- Standby Mode: 0.3 W (typ.)
- Off Mode: Zero watts with AC switch
- Power LED Indicator: Operation - White, Standby mode - White (blinking)
Dimensions
- Product with stand (max height): 807 x 602 x 287 mm
- Product without stand: 807 x 369 x 107 mm
- Packaging: 930 x 525 x 188 mm
Weight
- Product with stand: 10.41 kg
- Product without stand: 7.82 kg
- Product with packaging: 15.35 kg
